标准贴片式(SMD), 2电极

技术规格

Bourns提供标准2电极贴片式气体放电管器件，击穿电压范围从75-600 V。这类型标准气体放电管有重型、中型及轻型版本，同样具备ITU K.12标准的性能表现。

GDT、SPD、MOV冲突矿源报告: CFSI_CMRT4-01

Product Series

Parametric Table

RoHS Files

Collateral

Videos

Request Samples

Series	数据表	描述	体积	电容 pF	直流击穿电压范围V	标称8/20μs脉冲放电电流(kA) 10	最大8x20μs脉冲电流（KA）1 应用	最大10x350μs脉冲电流（K）1应用	工作温度范围C°	包装选择	RoHS 规范	MDS	工程檔
GDT25	GDT25	Next-Generation Light Duty 2-Electrode Miniature GDT	5.4 x 4.1	0.7	75-600	7	10	1	-55 to +125	Tape & Reel	GDT25	GDT25
2003-xx-SM	2003	Light Duty 2-Electrode Micro GDT	2.8 x 3.5	<0.5	75-470	1	2	Not Rated	-40 to +90	Tape & Reel	2003-xx-SM	2003
2051-xx-SM		Light Duty 2-Electrode Micro GDT	3.2 x 4.5	<0.5	90-600	2	Not Rated	Not Rated	-40 to +125	Tape & Reel, Bulk	2051-xx-SM	2051-xx-SM	Downloads
2053-xx-SM		Light Duty 2-Electrode Miniature GDT	4 x 4.2	<1	75-600	3	5	Not Rated	-40 to +85	Tape & Reel, Bulk	2053-xx-SMLF	2053-xx-SMLF	Downloads
2035-xx-SM		Long Life Light Duty 2-Electrode Miniature GDT	5 x 4.4	<1	90-600	5	10	1	-55 to +85	Tape & Reel, Bulk	2035-xx-SMLF	2035-xx-SMLF	Downloads
2055-xx-SM	2055	Light Duty 2-Electrode Miniature GDT	6.2 x 4.2	<1	75-800	5	8	Not Rated	-30 to +85	Tape & Reel, Bulk	2055-xx-SMLF	2055-xx-SMLF
2027-xx-SM		Long Life Heavy Duty 2-Electrode GDT	7.92 x 6.42	<1	75-600	10	25	2.5	-55 to +125	Tape & Reel, Bulk	2027-xx-SMLF	2027 and 2029-XX-SMLF MDS	Downloads
2029-xx-SMLF	2029-xx-SMLF	Long Life Heavy Duty 2-Electrode GDT	8 x 6	<1	90-420	20	25	5	-55 to +105	Tape & Reel, Bulk	2029-xx-SMLF	2027 and 2029-XX-SMLF MDS

Bourns 新一代 GDT 提供最先进的性能表现标准浪涌电流额定值将大幅提高 40%

Advancing GDT Technology to Meet Higher Surge and Multi-level Protection Requirements White Paper

Bourns Next-Generation 2-electrode Gas Discharge Tube New Product Brief

气体放电管简表目录

Model/Datasheet	潮湿敏感度等级 MSL	焊接图表	封装标签	端子	RoHS 规范证书 CofC	第三方测试报告	物质资料表 MDS	China RoHS
2026-xx-XX	1	GDT TP	TBD	e3	GDT	Request Report	2026-xx-XXLF	China RoHS2 - GDT
2036-xx-SM	1	GDT TP	TBD	e3	GDT	Request Report	2036-xx-SMLF	China RoHS2 - GDT
2036-xx-XX	1	GDT TP	TBD	e3	GDT	Request Report	2036-xx-XXFLF	China RoHS2 - GDT
2026-xx-xx-MSP	1	GDT TP	TBD	e3	GDT	Request Report	2026-xx-XX-MSP	China RoHS2 - GDT
2038-xx-SM	1	GDT TP	TBD	e3	GDT	Request Report	2038-xx-SMLF	China RoHS2 - GDT
2027-xx-XX	1	GDT TP	TBD	e3	GDT	Request Report	2027-xx-XXLF MDS	China RoHS2 - GDT
2027-xx-SM	1	GDT TP	TBD	e3	GDT	Request Report	2027 and 2029-XX-SMLF MDS	China RoHS2 - GDT
2037-xx-XX	1	GDT TP	TBD	e3	GDT	Request Report	2037-xx-XXLF	China RoHS2 - GDT
2035-xx-XX	1	GDT TP	TBD	e3	GDT	Request Report	2035-xx-XXLF	China RoHS2 - GDT
2035-xx-SM	1	GDT TP	TBD	e3	GDT	Request Report	2035-xx-SMLF	China RoHS2 - GDT
2039-xx-SM	1	GDT TP	TBD	e3	GDT	Request Report	2039-xx-SMLF	China RoHS2 - GDT
2020-xxT	1	GDT TP	TBD		GDT	Request Report	2020-xxT	China RoHS2 - GDT
2030-xxT-SM	1	GDT TP	TBD	e3	GDT	Request Report	2030-23T-SMLF 2030-42T-SMLF	China RoHS2 - GDT
2031-xxT-SM	1	GDT TP	TBD	e3	GDT	Request Report	2031-xxT-SM	China RoHS2 - GDT
2045-xx-XX	1	GDT TP	TBD	e3	GDT	Request Report	2045-xx-XXLF	China RoHS2 - GDT
2046-xx-XX	1	GDT TP	TBD	e3	GDT	Request Report	2046-xx-XXLF	China RoHS2 - GDT
2047-xx-A	1	GDT TP	TBD	e3	GDT	Request Report	2047-xxALF	China RoHS2 - GDT
2049-xx-XX	1	GDT TP	TBD	e3	GDT	Request Report	2049-xx-XXLF	China RoHS2 - GDT
2051-xx-SM	1	2051 Profile	TBD	e3	GDT	Request Report	2051-xx-SM	China RoHS2 - GDT
2052-xx-SM	1	GDT TP	TBD	e3	GDT	Request Report	2052-xx-SMLF	China RoHS2 - GDT
2053-xx-SM	1	GDT TP	TBD	e3	GDT	Request Report	2053-xx-SMLF	China RoHS2 - GDT
2054-xx-SM	1	GDT TP	TBD	e3	GDT	Request Report	2054-xx-SM	China RoHS2 - GDT
2055-xx-SM	1	GDT TP	TBD	e3	GDT	Request Report	2055-xx-SMLF	China RoHS2 - GDT
2056-xx-XX	1	GDT TP	TBD	e3	GDT	Request Report	2056-xx-XXLF	China RoHS2 - GDT
2057-xx-XX	1	GDT TP	TBD	e3	GDT	Request Report	2057-xx-XXLF	China RoHS2 - GDT
2061-xx-A	1	GDT TP	TBD	e3	GDT	Request Report	2061-xx-ALF	China RoHS2 - GDT
2063-xx-A	1	GDT TP	TBD	e3	GDT	Request Report	2063-xx-ALF	China RoHS2 - GDT
2087-xxx-SM	1	GDT TP	TBD	e3	GDT	Request Report	2087-xxx-SM	China RoHS2 - GDT
2089-xxx-X	1	GDT TP	TBD	e3	GDT	Request Report	2089-xxx-X	China RoHS2 - GDT
2093-xxx-SM	1	GDT TP	TBD	e3	GDT	Request Report	2093-xxx-SM	China RoHS2 - GDT
2095-xxx-X	1	GDT TP	TBD	e3	GDT	Request Report	2095-xxx-X	China RoHS2 - GDT
2097-xxx-D	1	GDT TP	TBD	e3	GDT	Request Report	2097-xxx-DLF	China RoHS2 - GDT
SA2-xxxx-XXX-STD	1	GDT TP	TBD	e3	SA2 COC	Request Report	SA2-xxxx-XXX-STD	China RoHS2 - GDT
2029-xx-SMLF	1	GDT TP	TBD	e3	GDT	Request Report	2027 and 2029-XX-SMLF MDS	China RoHS2 - GDT
2017 Series w/FLAT® Technology	1	GDT TP	TBD	e3	GDT	Request Report	2017 FLAT	China RoHS2 - GDT
2018 Series w/FLAT® Technology	1	GDT TP	TBD	e3	GDT	Request Report	2018-FLAT	China RoHS2 - GDT
2003-xx-SM	1	TBD	TBD	e3	GDT	Request Report	2003	China RoHS2 - GDT
2033-xxx-G5-xxLF	1	2033-xxx-G5-xxLF	TBD	e3	GDT	Request Report	2033	China RoHS2 - GDT
2036-xx-SM-H	1	GDT TP	TBD	e3	GDT	2036-xx-SM-H	2036-xx-SM-H	China RoHS2 - GDT
2019 Series w/FLAT® Technology	1	GDT TP	TBD	e3	GDT	Request Report	2019 FLAT	China RoHS2 - GDT
2011 Series w/FLAT® Technology	1	GDT TP	TBD	e3	GDT	Request Report	2011 FLAT	China RoHS2 - GDT
GDT25	1	See Data Sheet	TBD	e3	GDT	Request Report	GDT25	China RoHS2 - GDT
GDT35	1	See Data Sheet	TBD	e3	GDT	Request Report	GDT35	China RoHS2 - GDT
