Automotive Grade Power Transformers

Quick links to product tables:

Automotive Grade Power Transformers
Automotive Grade BMS Transformers
Automotive-Grade LAN Transformers

Automotive Grade Power Transformers

Series	Data Sheet	Photo	Size	Input Voltage	Output Voltage	Output Current	Frequency	MDS	Design Files	Engineering	Buy Now
BA60951CS			16.9 x 10.5 x 5.97 mm	7 - 24 VDC	15 VDC	0.15 A	120 kHz	BA60951CS	Downloads		Buy
HCT			15.2 x 10.8 x 6.5 mm	3.3 - 5 VDC	3.3 - 15 VDC	0.35 A Peak	250 - 550 kHz	HCTSM8	Downloads		Buy
HCT8xxxxEAL			14.2 x 10.6 x 8.0 mm	3.3 - 5 VDC	3.3 - 15 VDC	0.35 A Peak	250 - 550 kHz	HCT8xxxxEAL	Downloads		Buy
HCTSM100308BAL			15.7 x 10.8 x 7.5 mm	3.3 - 5 VDC	8 - 12 VDC	0.125 A	350 kHz	HCTSM100308BAL	Downloads		Buy
HCTSM110102HAL			19.6 x 13.5 x 9.6 mm	3.3 - 5 VDC	6.5 - 10 VDC	0.25 A	350 kHz	TBD	Downloads		Buy
HCTSM110103HAL			19.6 x 13.5 x 9.6 mm	5 V	15 V	0.25 A	250~550 kHz	HCTSM110103HAL	Downloads		Buy
HCTSM110304HAL			19.6 x 13.5 x 9.6 mm	3.3 - 5 VDC	4.3 - 6.5 VDC	0.25 A	350 kHz	TBD	Downloads		Buy
HCTSM151207FAL			21.3 x 15.0 x 9.6 mm	24 VDC	12 VDC	0.10 A	100 kHz - 1 MHz	HCTSM151207FAL	Downloads		Buy
HVMA01F35A-ST10S			10.3 x 9.5 x 12.2 mm	6-27 VDC	14 VDC	0.2 A	100 - 400 kHz	HVMA01F35A-ST10S	Downloads		Buy
HVMA03F40C-ST10S			10.3 x 9.5 x 12.2 mm	6-27 VDC	14 VDC	0.2 A	12 kHz - 400 kHz	HVMA03F40C-ST10S	Downloads		Buy
HVMA03F4A-LP8S			12.8 x 10 x 7.0 mm	10-24 VDC	15 VDC	0.1 A	400 kHz	HVMA03F4A-LP8S	Downloads		Buy
HVMA03T100A-ST10S			9.5 x 10.3 x 13.2 mm	Sec1 15 VDC , Sec2 4 VDC	0 - 12 VDC	0.1 A	300 - 400 kHz	HVMA03T100A-ST10S	Downloads		Buy
PKSEP6			9.0 x 7.8 x 7.6 mm	12 - 24 VDC	3.3 - 5 VDC	0.03 A	51.2 kHz	PKSEP6B08S	Downloads		Buy
SM91259AL			14.5 x 12 x 14 mm	7~16 VDC	12 VDC	0.5 A	120 kHz	SM91259AL	Downloads		Buy

Automotive Grade BMS Transformers

Series	Data Sheet	Photo	Description	Mount	MDS	Design Files	Engineering	Buy Now
SM91501AL			BMS Transformer/CMC, Dual Channel	SMT	SM91501AL	Downloads		Buy
SM91501ALO			BMS Transformer with Common Mode Chokes, AEC-Q200 Compliant, Dual Channel, 125 °C, 4.3k VAC	SMT	SM91501ALO	Downloads		Buy
SM91502AL			BMS Transformer/CMC, Single Channel	SMT	SM91502AL	Downloads		Buy
SM91502ALA			BMS Transformer with Common Mode Chokes, AEC-Q200 Compliant, Single Channel, 125 °C, 4.3k VDC	SMT	SM91502ALA	Downloads		Buy
SM91508AL			BMS Transformer/CMC, Single Channel	SMT	SM91508AL	Downloads		Buy
SM91509AL			BMS Transformer/CMC, Dual Channel	SMT	SM91509AL	Downloads		Buy
SM91514AL			Signal BMS Transformer with Common Mode Chokes, 125 °C, 4.3k Vdc, AEC-Q200 Compliant	SMT	SM91514AL	Downloads		Buy
SM91523AL			BMS Transformer/CMC, 6 Pins, SGL, 3.5k VAC, -40 °C to +125 °C	SMT	SM91523AL	Downloads		Buy
SM91525AL			BMS Transformer with Common Mode Chokes, AEC-Q200 Compliant, 6-Pin, Single Channel, 4.3k VDC	SMT	TBD	Downloads		Buy
SM91534AL			BMS Transformer with Common Mode Chokes, 6 Pins, 6.4k VDC, -40 to 125 °C	SMT	SM91534AL	Downloads		Buy
SM91536AL			BMS Transformer with Common Mode Chokes, 6 Pins, SGL, 3.0K VAC, -40 to 125 °C	SMT	SM91536AL	Downloads		Buy
SM91542AL			BMS Transformer with Common Mode Chokes, 6 Pin, Signal, 4.3k VDC, –40 to +125 °C	SMT	SM91542AL	Downloads		Buy
SM91543AL			BMS Transformer with Common Mode Chokes, 6 Pins, Signal, 5600 VAC or 8000 VDC	SMT	SM91543AL	Downloads		Buy
SM91574AL			BMS Transformer with Common Mode Chokes, 6 Pins, Signal, 3k VAC, -40 °C to +125 °C	SMT	SM91574AL	Downloads		Buy
SM91801AL			BMS Planar Transformer, Signal, 6 Pins, 4300 VDC, -40 to +125 ℃	SMT	SM91801AL	Downloads		Buy
SM91803AL			BMS Transformer, Signal, 6 Pins, 4.3k VDC	SMT	TBD	Downloads		Buy
SM91806AL			BMS Planar Transformer, Signal, 6 Pins, 4300 VDC, -40 to +125 °C	SMT	SM91806AL	Downloads		Buy
SM91808AL			BMS Planar Transformer, Single Channel, 6 Pin, 4.3k VDC, -40 ℃ to +125 ℃	SMT	TBD	Downloads		Buy
SM91872AL			BMS Transformer, 6 Pins, SIN, 4.0k VAC, –40 °C to +125 °C Temperature Range	SMT	SM91872AL	Downloads		Buy

Automotive-Grade LAN Transformers

Series	Data Sheet	Photo	Description	Mount	MDS	Design Files	Engineering	Buy Now
SM453229A-381N7Y			Chip LAN Transformer, 10/100/1000 Base-T, AEC-Q200 Compliant, 4.7 x 3.3 x 2.9 mm	SMT	SM453229A-381N7Y	Downloads		Buy
SM91071AL			LAN 10/100 Base-T, 125 °C, AEC-Q200 Compliant, Common Mode Choke on Cable Side	SMT	SM91071AL	Downloads		Buy
SM91072AL			LAN 10/100 Base-T, 125 °C, AEC-Q200 Compliant, Common Mode Choke on Chip Side	SMT	SM91072AL	Downloads		Buy
SM91074AL			LAN 10/100 Base-T, 125 °C, AEC-Q200 Compliant, Common Mode Choke on Cable Side, With Wire Pre-Soldering for Higher Reliability	SMT	SM91074AL	Downloads		Buy
SM91604L			LAN Transformer with Common Mode Chokes, 24-Pin, 1000Base, 4.68k VDC, -40 to +105 °C	SMT	SM91604L	Downloads		Buy
