Thin Film Chip Resistors

Quick link to the Sample Request: Request Sample
CRT0402_sm
Bourns precision thin film resistors have tight resistance tolerances, extremely low temperature coefficiency and wide range of resistance value which makes them ideal for high precision applications. Excellent stability, low noise characteristics are achieved by using thin film sputtering technology on ceramic substrates and high precision laser trimming process.
Characteristics
Size 0402 to 1206 (1005 to 3015 Metric)
Rated power at 70 °C 0.0625 to 0.25 W
Resistance Range 1 ohm to 2.49 megohms
Resistance Tolerance ±0.01 to ±1 %
Temperature Coefficient ± 2 to ±50 ppm/°C
Operating Temperature Range –55 to +155 °C



Available features

  • Ultra-tight tolerance
  • Wide resistance range
  • Low TCR
  • Sulfur resistant available
  • Low current noise
  • Low parasitic inductance
  • RoHS compliant*
  • Suitable for most types of soldering processes
  • Standard packaging on paper tape and reel
*RoHS Directive 2015/863, Mar 31, 2015 and Annex.

Applications

  • Consumer
  • Industrial
  • Telecommunication
  • Current sensing
  • Precision circuits
  • Medical equipments
  • Audio devices
  • High Frequency circuits
  • Printers
  • Automation equipment
  • Navigation equipment
Series Data Sheet Photo Resistance Range Tolerances Temperature Coefficient Power per Resistor Related Documents Design Files Engineering Buy Now
CRT0402 CRT0402 CRT0603_part 4.7 ohms to 511K ohms 0.01 % to 1 % ±2 to ±50 ppm .0625 W CRT0402
Downloads Buy
CRT0603 CRT0603 CRT0603_part 4.7 ohms to 1 megohm 0.01 % to 1 % ±2 to ±50 ppm .100 W CRT0603
Downloads Buy
CRT0805 CRT0805 CRT0603_part 1 ohm to 1 megohm 0.01 % to 1 % ±2 to ±50 ppm .125 W CRT0805
Downloads Buy
CRT1206 CRT1206 CRT0603_part 4.7 ohms to 1 megohm 0.01 % to 1 % ±2 to ±50 ppm .250 W CRT1206
Downloads Buy
CRT0402-ST CRT0402-ST CRT0603_part 4.7 ohms to 255K ohms 0.1 % to 1 % ±25 ppm / ±50 ppm 0.0625 W CRT0402-ST
Downloads Buy
CRT0603-ST CRT0603-ST CRT0603_part 1 ohm to 1 megohm 0.1 % to 1 % ±25 ppm / ±50 ppm 0.1 W CRT0603-ST
Downloads Buy
CRT0805-ST CRT0805-ST CRT0603_part 1 ohm to 2 megohms 0.1 % to 1 % ±25 ppm / ±50 ppm 0.125 W CRT0805-ST
Downloads Buy
CRT1206-ST CRT1206-ST CRT0603_part 1 ohm to 2.49 megohms 0.1 % to 1 % ±25 ppm / ±50 ppm 0.25 W CRT1206-ST
Downloads Buy
CRT0402-AS CRT0402-AS CRT-AS_part 49.9 ohms to 332K ohms 0.05 % to 1 % ±10 to ±50 ppm .0625 W CRT0402-AS
Downloads Buy
CRT0603-AS CRT0603-AS CRT-AS_part 49.9 ohms to 332K ohms 0.05 % to 1 % ±10 to ±50 ppm .100 W CRT0603-AS
Downloads Buy
CRT0805-AS CRT0805-AS CRT-AS_part 10 ohms to 1 megohm 0.05 % to 1 % ±10 to ±50 ppm .125 W CRT0805-AS
Downloads Buy
CRT1206-AS CRT1206-AS CRT-AS_part 10 ohms to 1 megohm 0.05 % to 1 % ±10 to ±50 ppm .250 W CRT1206-AS
Downloads Buy
